Description
TSP's new compact e-core ignition coil puts out 40,000 volts, giving you a much hotter and larger spark to burn fuel more efficiently and provide smooth acceleration throughout the entire RPM band. It's small design allows for easy mounting, and the brass terminal ensures maximum conductivity.
SPECIFICATIONS :
COIL STYLE: E-core
INTERNAL CONSTRUCTION: Epoxy
PRIMARY RESISTANCE: 0.355 ohms (Ω)
SECONDARY RESISTANCE: 4,400 ohms (Ω)
MAXIMUM VOLTAGE: 40,000 volts (V)
SPARK DURATION: 220 microseconds (µS)
PEAK CURRENT: 300 milliamperes (mA)
TURNS RATIO: 70:1
INDUCTANCE: 6.9 millihenrys (mH)
COIL SHAPE: Square
COIL WIRE ATTACHMENT: Male
HARDWARE: Included
FITMENT:
THIS PRODUCT IS UNIVERSAL
Intended for high-performance distributor ignition set-ups
SPECIFICATIONS :
COIL STYLE: E-core
INTERNAL CONSTRUCTION: Epoxy
PRIMARY RESISTANCE: 0.355 ohms (Ω)
SECONDARY RESISTANCE: 4,400 ohms (Ω)
MAXIMUM VOLTAGE: 40,000 volts (V)
SPARK DURATION: 220 microseconds (µS)
PEAK CURRENT: 300 milliamperes (mA)
TURNS RATIO: 70:1
INDUCTANCE: 6.9 millihenrys (mH)
COIL SHAPE: Square
COIL WIRE ATTACHMENT: Male
HARDWARE: Included
FITMENT:
THIS PRODUCT IS UNIVERSAL
Intended for high-performance distributor ignition set-ups
