Mobilgrease XHP 220 greases are extended service lithium complex greases intended for a wide variety of applications and severe operating conditions.These greases feature high dropping points and maximum recommended operating temperature of 140deg C (284°F). Mobilgrease XHP 220 greases are available in NLGI grades 00, 0, 1, 2 and 3 with an ISO VG 220 base oil viscosity. Mobilgrease XHP 220 greases are designed for a wide range of applications including the industrial, automotive, construction and marine sectors. Their performance features make them ideal choices for operating conditions including high temperature, water contamination, shock loading and extended re-lubrication operations. Mobilgrease XHP 222 Special is an extreme pressure grease fortified with 0.75% molybdenum disulfide that provides protection from wear under conditions pivoting and other conditions that lead to loss of oil film. Always consult your owner’s manual to check recommended viscosity grade and specifications.

Specifications and Approvals
Mobilgrease XHP 220 Series meets or exceeds the requirements of KP2N-2, Fives Cincinnati - P-64

Typical Properties
NLGI Grade -2
Thickener Type - Li-Complex
Color, Visual –Dark Blue
Penetration, Worked, 25deg C, ASTM 280 D 217 – 280
Dropping Point, degC, ASTM D 2265 -280
Viscosity of Oil, ASTM D 445
cSt @ 40deg C -220
4-Ball Wear Test, ASTM D 2266, scar, mm -0.5
4-Ball Weld Load, ASTM D 2596, kg -315
Timken OK Load, ASTM D 2509, lb -40
Bomb Oxidation, ASTM D 942,
Pressure drop at 100 hrs, kPa (psig) - 35 (5)
Corrosion Prevention, ASTM D 1743 –PASS
Rust Protection, IP 220-mod.Distilled Water Washout -0,0
Copper Strip Corrosion, ASTM D 4048 – 1B
Penetration Consistency Change, Roll Stability, ASTM D 1831, mm/10 -0
