Description
** NB – This item is very heavy & will be delivered by a Transport Company; someone will be required to be present at off-load. Mytools Free delivery offer only applies on this product for Business delivery or to your local Depot only.
Private House Dwelling delivery will incur additional Freight Charge imposed by the carriers – If in doubt, contact us in advance here: https://mytools.co.nz/pages/contact
Model Dpw25 - Garrick Workshop Pedestal Drill 25mm
Square Tables For Larger Work Area, With ‘T’ Slots For Solid Clamping
Tables Tilt And Rotate
Safety Guard With Flip Up Cover Over Chuck As Standard
Emergency Stop Switches
Heavy-Duty Precision Depth Stops
Quick Action, Positive Motor Adjustment For Belt Tensioning
Rack & Pinion Table Height Adjustment
Column & Quill Precision Machined From Thick Wall Tube For Rigidity
Includes Drill Chuck & Arbor, Chuck Key And Drill Drift
Model Dpw25
Type Pedestal
Motor 650W
Max Drilling Capacity 25mm
Chuck Size (mm) 3 - 16
Swing (mm) 220
Spindle Taper Mt3
Spindle Travel (mm) 80
No. Of Speeds 12
Speed Range (Rpm) 120 - 2580
Overall Height (mm) 1650
Column Diameter (mm) 70
Quill Diameter 52
Table Dimensions (mm) 295 x 295
Slot size (mm) 16
Weight (Kg) - Nett / Gross 61 / 67
NB - This item is very heavy & will be delivered by a Transport Company, someone will need to be present to off-load!
Please also provide a contact ph number for delivery .
Private House Dwelling delivery will incur additional Freight Charge imposed by the carriers – If in doubt, contact us in advance here: https://mytools.co.nz/pages/contact
Model Dpw25 - Garrick Workshop Pedestal Drill 25mm
Square Tables For Larger Work Area, With ‘T’ Slots For Solid Clamping
Tables Tilt And Rotate
Safety Guard With Flip Up Cover Over Chuck As Standard
Emergency Stop Switches
Heavy-Duty Precision Depth Stops
Quick Action, Positive Motor Adjustment For Belt Tensioning
Rack & Pinion Table Height Adjustment
Column & Quill Precision Machined From Thick Wall Tube For Rigidity
Includes Drill Chuck & Arbor, Chuck Key And Drill Drift
Model Dpw25
Type Pedestal
Motor 650W
Max Drilling Capacity 25mm
Chuck Size (mm) 3 - 16
Swing (mm) 220
Spindle Taper Mt3
Spindle Travel (mm) 80
No. Of Speeds 12
Speed Range (Rpm) 120 - 2580
Overall Height (mm) 1650
Column Diameter (mm) 70
Quill Diameter 52
Table Dimensions (mm) 295 x 295
Slot size (mm) 16
Weight (Kg) - Nett / Gross 61 / 67
NB - This item is very heavy & will be delivered by a Transport Company, someone will need to be present to off-load!
Please also provide a contact ph number for delivery .
