ITM Dee Shackle-Yellow Pin GS Screw Pin-0.75 Ton-8mm Body
Description
TM9200-00708| ITM Dee Shackle, Yellow Pin GS Screw Pin, 0.75 Ton, 8mm Body
• Drop forged, quenched and tempered
• Galvanised finish
• Tested and certified to AS 2741
• Maximum proof load of 2 times W.L.L
• Minimum breaking force of 6 times W.L.L
• Nominal Size: 8mm (5/16")
• W.L.L.: 0.75 T
• Dimension (mm):
A: 13
B: 10
C: 27
• Weight: 0.08kg
• Drop forged, quenched and tempered
• Galvanised finish
• Tested and certified to AS 2741
• Maximum proof load of 2 times W.L.L
• Minimum breaking force of 6 times W.L.L
• Nominal Size: 8mm (5/16")
• W.L.L.: 0.75 T
• Dimension (mm):
A: 13
B: 10
C: 27
• Weight: 0.08kg
