Description
Extreme power with 21.4J of impact energy
Active feedback sensors shut down the tool in the event of a kickback
Anti-vibration technology provides extremely low vibration of 8.5m/s2
Soft no load function reduces speed and vibration when under no lead for improved comfort
Compatible with AWS* for wireless connectivity with compatible dust extraction
**Requires optional wireless transmitter
Specifications
Shank type SDS-max
Capacities 1100 - 2250 BPM
- Concrete Concrete (w/ TCT Bit): 52mm
- Concrete (Core bit) Concrete (w/ Core Bit): 160mm
Impacts per minute 1100 - 2250
Joules 21.4J
Overall dimensions 610 x 140 x 337mm
Net weight (skin) 12.9kg
Sound Level 110dB(A)
Voltage 40Vx2 (80V)
Included accessories
(135283-4) Side Handle Assembly, Side Grip, Depth Gauge, (194683-7) 100mL Grease, Cloth and (821848-5) Carry Case
Optional accessories
(199144-2) Dust Extractor Set
(199766-8) Wireless unit adaptor with AWS chip (WUT02ZU)
(198901-5) AWS Auto‑Start Wireless Transmitter
(PDC1200) Portable Backpack battery 33.5Ah 1200Wh
