Description
Metabo Quick for changing saw blades without tools
Low-lying saw blade guidance for precise cuts
Top handle with non-slip soft-grip surface
Selectable chip blowing function ensures free view of cutting line
Variospeed (V) Electronics for working with customised stroke rates for the materials used
Extraction possibility by means of connecting an all-purpose vacuum cleaner
Precision guide rail and guiding device available as accessory
Rated input power590 W
Output power350 W
Cutting depth wood80 mm
Cutting depth NF metal25 mm
Cutting depth sheet steel8 mm
Swivel range from / to:- 45 / + 45 °
Pendulum stroke levels4
Strokes in idle900 - 3300 rpm
Saw blade stroke22 mm
Weight (without power cable)2 kg
Cable length2.4 m
Vibration
Sawing wood12 m/s²
Uncertainty of measurement K2 m/s²
Sawing metal8.5 m/s²
Uncertainty of measurement K2 m/s²
Noise emission
Sound pressure level89 dB(A)
Sound power level (LwA)100 dB(A)
Uncertainty of measurement K3 dB(A)
