Description
SBEV1000-2
Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
Thumbwheel for Speed Preselection
Robust die cast aluminium gear housing for optimum heat dissipation and long service life
Rotating carbon brush bridge for maximum performance even in anti-clockwise operation, e.g. for the removal of stubborn screws
Metabo Marathon-motor with dust protection for long service life
Metabo S-automatic safety clutch: mechanical decoupling of the drive for safe working should the tool stop unexpectedly
Forward and reverse rotation
Spindle with hexagonal recess for screwdriver bits for working without chuck
Restart protection: prevents unintentional start-up after power supply interruption
Cable-protecting ball joint for optimal freedom of motion when working
With metaBOX, the intelligent solution for transport and storage
Rated input power1010 W
Output power540 W
Maximum torque40 / 14 Nm // 354 / 124 in-lbs
Drill-Ø masonry22 mm / 7/8 "
Drill-Ø concrete20 mm / 25/32 "
Drill Ø steel16 / 10 mm // 5/8 / 3/8 "
Drill-Ø soft wood40 / 25 mm // 1 9/16 / 1 "
No-load speed0 - 1000 / 0 - 2800 rpm
Revolutions at rated load1000 / 2800 rpm
Maximum impact rate53200 bpm
Gears2
Chuck capacity1.5 - 13 mm // 1/16 - 1/2 "
Collar diameter43 mm / 1 11/16 "
Drill spindle with hexagonal recess6.35 mm / 1/4 "
Drill spindle thread1/2 " - 20 UNF
Chuck clamping typeKeyless chuck
Weight (without power cable)2.7 kg / 6 lbs
Cable length4 m / 13 ft
Vibration
Drilling in metal4.2 m/s²
Uncertainty of measurement K1.5 m/s²
Impact drilling concrete17 m/s²
Uncertainty of measurement K1.5 m/s²
Noise emission
Sound pressure level103 dB(A)
Sound power level (LwA)114 dB(A)
Uncertainty of measurement K3 dB(A)
