Description
Pump displacement: 970L/min (34.3 cfm)
Free Air Delivery: 610L/min (21.6 cfm)
Pump cylinders: 3
Pump speed: 786 rpm
Pressure Cut In: 6.0 bar (95 psi)
Pressure Cut Out: 8.0 bar (125 psi)
Max Pressure Cut Out: 9.0 bar (150 psi)
Min Pressure Cut In: 2.4 bar (35 psi)
Pressure Differential: 2.07 – 2.76 bar (30-40 psi)
Tank Size: 170 Litres
Tank Approval: AS 1210: 1997 Class 3 + Amdt 3
Tank Design Verification Number: A 1730 V/01
Motor: 3 Phase 4.0 kw TECO (AUSTRALIA)
Motor Dimensions
Length: 148 cm
Width: 52 cm
Height: 92 cm
Weight: 295 kg
1 Year Warranty
Free Air Delivery: 610L/min (21.6 cfm)
Pump cylinders: 3
Pump speed: 786 rpm
Pressure Cut In: 6.0 bar (95 psi)
Pressure Cut Out: 8.0 bar (125 psi)
Max Pressure Cut Out: 9.0 bar (150 psi)
Min Pressure Cut In: 2.4 bar (35 psi)
Pressure Differential: 2.07 – 2.76 bar (30-40 psi)
Tank Size: 170 Litres
Tank Approval: AS 1210: 1997 Class 3 + Amdt 3
Tank Design Verification Number: A 1730 V/01
Motor: 3 Phase 4.0 kw TECO (AUSTRALIA)
Motor Dimensions
Length: 148 cm
Width: 52 cm
Height: 92 cm
Weight: 295 kg
1 Year Warranty
