Description
Rated frequency (Hz) 50
Rated voltage (V) 230
Phase No. Single
Rated output (kW) 3.6
Max. output (kW) 4.0
Rated current (A) 15.2
Starting system Electric & Recoil
Power factor Ø 1
Engine type 1 cylinder, 4 stroke, air cooled, OHV
Noise level dB @ 7m 60
Displacement (cc) 223
Ignition system TCI
Rated rotation speed 3600
Low oil alarm system Yes
Spark plug F6RTC/F7RTC
Fuel type 91 Unleaded
Fuel tank capacity (L) 9
Full tank operating time (Hr/Rated load) 7
Engine oil type 15W-30
Oil capacity (L) 0.6
Compression ratio 8.5:1
Dimensions (LxWxH)mm 592x575x500
Weight (kg) 50
Rated voltage (V) 230
Phase No. Single
Rated output (kW) 3.6
Max. output (kW) 4.0
Rated current (A) 15.2
Starting system Electric & Recoil
Power factor Ø 1
Engine type 1 cylinder, 4 stroke, air cooled, OHV
Noise level dB @ 7m 60
Displacement (cc) 223
Ignition system TCI
Rated rotation speed 3600
Low oil alarm system Yes
Spark plug F6RTC/F7RTC
Fuel type 91 Unleaded
Fuel tank capacity (L) 9
Full tank operating time (Hr/Rated load) 7
Engine oil type 15W-30
Oil capacity (L) 0.6
Compression ratio 8.5:1
Dimensions (LxWxH)mm 592x575x500
Weight (kg) 50
